The Highest Level of Casting and Machining Combined
Our precision steel castings with CNC machining are designed for the most demanding applications. We use the lost-wax investment casting process, which provides high detail and a smooth surface finish. This allows us to produce complex components such as impellers, turbine parts, and medical instruments. The casting is so precise that only a few critical areas require machining. Since 2009, we have been producing custom metal parts, and our IATF16949 certification ensures strict adherence to quality standards.
Near-Net Shape Casting for Complex Details
We start with a wax model that replicates every design detail, which is then coated with ceramic to create the mold. After removing the wax, we pour in high-quality steels such as stainless steel CF8M, 17-4PH, or high-alloy steels. The resulting casting has an exceptionally smooth surface finish, down to Ra 3.2 μm, and maintains high dimensional accuracy within ±0.13 mm per 25 mm (CT4 to CT6 grade). Post-casting solution treatment and aging maximize the material's strength and toughness.
| Specification | Details |
| Process | Investment Casting (Lost-Wax) + CNC Machining |
| Materials | Stainless Steel CF8M, 17-4PH, High-Alloy Steels |
| Casting Tolerance | CT4 to CT6 (±0.13 mm per 25 mm) |
| Surface Finish (as cast) | Ra 3.2 μm or better |
| Key Applications | Impellers, Turbine Housings, Medical Instruments, Aerospace Parts |
Micro-Level Finishing for Critical Surfaces
Because the casting is highly accurate, precision steel casting is minimal, focused only on critical features. This includes grinding sealing faces, boring bearing holes, and drilling dowel pin holes, performed with very light cuts to preserve accuracy. Additional treatments such as electropolishing or passivation can be applied for enhanced corrosion resistance. We provide transparent pricing and timelines, and respond to inquiries within 24 hours. The result is a component that combines precision, durability, and the craftsmanship of a work of art in metal.
