Tapered Shaft Connecting Flange

The tapered shaft connecting flange is a category of part we are quite good at and confident in. Unlike ordinary flat-key flanges, it grips the shaft through taper interference fit rather than transmitting force through a keyway. The benefits are straightforward: high torque transmission, good alignment, and assembly/disassembly without damaging the shaft. When making a Tapered shaft connecting flange, the greatest test is the taper surface workmanship-if the taper is wrong or the contact rate is insufficient, the two parts are in "false contact" once installed, and they simply cannot hold up at high speeds.

We commonly produce tapers of 1:10, 1:15, and 1:20. The taper surface is checked with blueing, achieving a contact rate above 85%. The surface is ground to within Ra0.4μm and then super-finished to ensure uniform contact with the shaft. The material is 42CrMo, quenched and tempered; the inner taper surface can be nitrided to hardness above HV700, resisting fretting wear even with frequent assembly and disassembly. A Tapered shaft connecting flange made this way remains stable after dozens of assembly-disassembly cycles-unlike keyways that "chew out" over time. Tapered shaft connecting flanges are mainly used in high-speed spindles, fan impellers, water pumps, mixers, and crushers-applications requiring frequent maintenance or high dynamic balance standards. We support customization to your shaft diameter and taper, and can also machine hydraulic oil injection/pressure relief channels for easier assembly and disassembly. Every piece undergoes overall dynamic balancing before shipping, achieving grade G2.5 or above for stable rotation at high speeds. This product is completed entirely in-house from blank forging to grinding, managed under IATF 16949, and third-party inspection is accepted. If you have a sample or drawing, send it over and we will make a sample-typically ready in 15–20 working days. Try a small batch first, and scale up once satisfied.

● High-speed spindles, fan impellers

● Water pumps, mixers, crushers

● Large pump bodies, power generation and drive equipment

● Drive applications requiring frequent assembly/disassembly maintenance

Taper, shaft diameter, and length can be customized per drawing. Hydraulic oil injection/pressure relief channels and keyway anti-rotation structures can be machined. Drawings and samples both accepted, no strict MOQ. Custom samples take 15–20 working days, appropriately longer for complex processes. A small sample fee is charged, fully deductible against bulk orders.

Taper surface contact rate is checked piece by piece with blueing. Dynamic balance is tested per G2.5 and above standards. Key dimensions are rechecked on a CMM. Operating under IATF 16949: from incoming material inspection to 100% final inspection before shipment, third-party inspection is accepted.

Parts are sleeved in PE mesh bags and placed in plywood wooden boxes with VCI vapor-phase rust inhibitor strips. Shipping marks, product name, quantity, and other customs clearance information are labeled externally. All packaging is export-reinforced. For transit damage, the customer provides photos/videos within 3 working days; we verify immediately. If it is our responsibility, free replacement or partial refund; for logistics causes, we fully assist in claims.
